Switch & relay for GS300 / 400 / 430 UZS160L
Click on the part subgroup below to get genuine part numbers.
Scheme 1
|
Click part number in the scheme or in the list: 89615 SENSOR, KNOCK CONTROL9165140830 ** Std Part 84540 SWITCH ASSY, NEUTRAL START 89465 SENSOR, OXYGEN 91651B0616 ** Std Part 83530 SWITCH ASSY, OIL PRESSURE (FOR ENGINE) 89428 SWITCH, TEMPERATURE DETECT, NO.2 89491A GASKET, ENGINE OIL LEVEL SENSOR 89491 SENSOR, ENGINE OIL LEVEL |
Scheme 2
Scheme 3
|
Click part number in the scheme or in the list: 81980 FLASHER ASSY, TURN SIGNAL82600F FUSE,FUSE BLOCK 85916N RELAY, TAIL LAMP ** 82-02 85916D RELAY, FOG LAMP 85912 RELAY, DEFOGGER ** 86-01 85910C RELAY ASSY (FOR HEATER BLOWER MOTOR) 85910X RELAY, HEATER MIRROR 28371 RELAY, IGNITION, NO.1 82673A BRACKET, JUNCTION BLOCK 82672A COVER, JUNCTION BLOCK 82602 BLOCK SUB-ASSY, RELAY 9011906245 ** Std Part 89221 COMPUTER, MULTIPLEX NETWORK BODY 82642A RELAY, RUNNING LIGHT 82861 BRACKET, COMPUTER INTEGRATION, NO.1 89111 COMPUTER, NETWORK GATEWAY 82673B BRACKET, JUNCTION BLOCK 84340 SWITCH ASSY, STOP LAMP 82733 BLOCK, PASSENGER SIDE JUNCTION 89650 COMPUTER ASSY, POWER STEERING 9163560616 ** Std Part 9017906239 ** Std Part 84550 SWITCH ASSY, PARKING BRAKE 9331315010 ** Std Part 82731 BLOCK, DRIVER SIDE JUNCTION 85903 COMPUTER SUB-ASSY, SHIFT LOCK CONTROL 89226B COMPUTER, MULTIPLEX NETWORK BODY, NO.2 |
Scheme 4
Scheme 5
|
Click part number in the scheme or in the list: 9046400551 ** Std Part9331914012 ** Std Part 85432 SOLENOID, KEY INTER LOCK 84450 SWITCH ASSY, IGNITION OR STARTER 84052 SWITCH ASSY, UN-LOCK WARNING 89227 COMPUTER, MULTIPLEX TILT & TELESCOPIC 84245 MODULATOR, STEERING PAD SWITCH 9331914006 ** Std Part 86174D CASE, SWITCH & VOLUME 84310 SWITCH ASSY, TURN SIGNAL 84650 SWITCH ASSY, WINDSHIELD WIPER 84140 SWITCH ASSY, HEADLAMP DIMMER 84306 CABLE SUB-ASSY, SPIRAL 89235 SWITCH, TILT STEERING 9331915012 ** Std Part |
Scheme 6
